Mean Well HEP-100-12A hep series industrial psu 12V 8.34A 100W IP65 aluminium

Mean Well
Order Code:

05-0765

Brand: Mean Well MPN: HEP-100-12A EAN-13: 4021087032513
Qty Unit Price (Ex VAT)
1+ £80.16
5+ £77.76
10+ £75.36
25+ £72.94
50+ £70.55
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well HEP-100-12A is an industrial power supply unit with an output of 12 V DC and 8.34 A, delivering 100 W of power. It features open end cables and is suitable for printed circuit board mounting with solder lugs. This robust PSU is ideal for demanding industrial applications requiring reliable power delivery.
Type Industrial PSU
Connection Open end cable
Dim (L x W x H) 220 x 68 x 38.8 mm
Height 38.8mm
Input voltage (max.) 305V AC
Length 220mm
Max. output current 8.34A
Min. input voltage 90V AC
Misc Attribute 2 closed
MTBF 167700h
Number of Outputs 1
Operating temperature (max.) 70°C
Operating temperature (min.) -55°C
Output current (max.) - rounded 8.34A
Output voltage (max.) 12V DC
PFC Yes
Power 100W
PSU features open cable ends
Width 68mm
