Mean Well ELG-240-54A-3Y LED driver 240.3W adjustable 48.6-59.4V DC

Mean Well
Order Code:

05-0494

Brand: Mean Well MPN: ELG-240-54A-3Y EAN-13: 4021087037815
Qty Unit Price (Ex VAT)
1+ £44.24
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well ELG-240-54A-3Y LED driver provides a constant voltage and current output, delivering 240.3 W with an adjustable range of 48.6 - 59.4 V DC and 2.23 - 4.45 A. It features surge protection, overvoltage protection, and a power factor correction circuit, making it suitable for installation on flammable surfaces. This transformer is ideal for powering LED strips and other LED lighting applications where reliability and
Type LED transformer
Connection Open end cable
Dim (L x W x H) 244 x 71 x 37.5 mm
Factory colour Metal
Height 37.5mm
Input voltage (max.) 305V AC
IP Rating IP65
Length 244mm
Max. output current 4.45A
Max. power 240.3W
Max. temperature 90°C
Min. input voltage 100V AC
Min. temperature -40°C
Misc Attribute Synchronised
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 4.45A
Output current (min.) 2.23A
Output voltage (max.) 59.4V DC
Output voltage (min.) 48.6V DC
Power (min.) 180.36W
Power range 180.36 up to 240.3 W
Protection Class I
Width 71mm
