Mean Well ELG-240-48A-3Y LED driver 240W 2.5-5A 43.2-52.8V DC IP65

Mean Well
Order Code:

05-0491

Brand: Mean Well MPN: ELG-240-48A-3Y EAN-13: 4021087037846
Qty Was Unit Price (Ex VAT)
1+ £41.16 £39.64
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

Mean Well's ELG-240-48A-3Y LED driver is a constant voltage and constant current LED transformer. It provides an adjustable 240 W power output with a current range of 2.5 - 5 A and a voltage range of 43.2 - 52.8 V DC. The driver is ideal for use on flammable surfaces, includes surge protection and overvoltage features, and has a PFC circuit, making it suitable for powering LED strips in various
Type LED transformer
Connection Open end cable
Dim (L x W x H) 244 x 71 x 37.5 mm
Factory colour Metal
Height 37.5mm
Input voltage (max.) 305V AC
IP Rating IP65
Length 244mm
Max. output current 5A
Max. power 240W
Max. temperature 90°C
Min. input voltage 100V AC
Min. temperature -40°C
Misc Attribute Synchronised
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 5A
Output current (min.) 2.5A
Output voltage (max.) 52.8V DC
Output voltage (min.) 43.2V DC
Power (min.) 180W
Power range 180 up to 240 W
Protection Class I
Width 71mm
