Mean Well ELG-200-C1750B-3Y ELG LED driver 199.5W 57-114V dimmable

Mean Well
Order Code:

05-0480

Brand: Mean Well MPN: ELG-200-C1750B-3Y EAN-13: 4021087037990
Qty Unit Price (Ex VAT)
1+ £43.39
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well ELG-200-C1750B-3Y LED driver provides a constant current of 1750 mA and supports a power output of 199.5 W, with voltage ratings ranging from 57 to 114 V DC. It is suitable for use on flammable surfaces and approved for furniture, featuring surge protection and a 3-in-1 dimmer. This LED driver is ideal for outdoor applications, offering reliability with PFC circuit integration.
Type LED driver
Connection Open end cable
Dim (L x W x H) 244 x 71 x 37.5 mm
Factory colour Metal
Height 37.5mm
IP Rating IP67
Length 244mm
Max. output current 1750mA
Max. power 199.5W
Max. temperature +85°C
Min. temperature -40°C
Misc Attribute 1 Constant current
Misc Attribute 2 Pulsed
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 1.75A
Output voltage (max.) 114V DC
Output voltage (min.) 57V DC
Power range 199.5 W (max)
Test mark CE, CB, MM, UL, ENEC
Width 71mm
