Mean Well ELG-150-36A-3Y LED driver adjustable 150W 32.4-39.6V IP65

Mean Well
Order Code:

05-0459

Brand: Mean Well MPN: ELG-150-36A-3Y EAN-13: 4021087038416
Qty Unit Price (Ex VAT)
1+ £32.26
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well ELG-150-36A-3Y is an LED driver that provides constant voltage and constant current with an adjustable output of 32.4-39.6 V DC and 2.1-4.17 A at a power rating of 150.1 W. It features surge protection, overvoltage protection, and a power factor correction circuit, making it suitable for use on flammable surfaces. Typically used for powering LED strips and lighting installations, this driver ensures
Type LED transformer
Connection Open end cable
Dim (L x W x H) 219 x 63 x 35.5 mm
Factory colour Metal
Height 35.5mm
Input voltage (max.) 305V AC
IP Rating IP65
Length 219mm
Max. output current 4.17A
Max. power 150.1W
Max. temperature 90°C
Min. input voltage 100V AC
Min. temperature -40°C
Misc Attribute Synchronised
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 4.17A
Output current (min.) 2.1A
Output voltage (max.) 39.6V DC
Output voltage (min.) 32.4V DC
Power (min.) 105W
Power range 105 up to 150.1 W
Protection Class I
Width 63mm
