Mean Well ELG-150-24DA-3Y LED driver 150W 6.25A DALI IP67 outdoor use

Mean Well
Order Code:

05-0458

Brand: Mean Well MPN: ELG-150-24DA-3Y EAN-13: 4021087038423
Qty Unit Price (Ex VAT)
1+ £33.57
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 12/12/2025

The Mean Well ELG-150-24DA-3Y LED driver operates with a constant voltage and current rating of 150 W and 6.25 A, delivering between 12 and 24 V DC. It includes a PFC circuit and surge protection, making it suitable for outdoor use and flammable surfaces. This LED transformer is typically used with LED lighting systems that require reliable power control and high efficiency.
Type LED transformer
Connection Open end cable
Dim (L x W x H) 219 x 63 x 35.5 mm
Factory colour Metal
Height 35.5mm
Input voltage (max.) 305V AC
IP Rating IP67
Length 219mm
Max. output current 6.25A
Max. power 150W
Max. temperature 90°C
Min. input voltage 100V AC
Min. temperature -40°C
Misc Attribute Synchronised
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 6.25A
Output voltage (max.) 24V DC
Output voltage (min.) 12V DC
Power (min.) 105W
Power range 105 up to 150 W
Protection Class I
Width 63mm
