Mean Well ELG-150-12A-3Y LED driver 120W 5-10A 13.2V IP65 surge protection

Mean Well
Order Code:

05-0453

Brand: Mean Well MPN: ELG-150-12A-3Y EAN-13: 4021087038485
Qty Unit Price (Ex VAT)
1+ £52.63
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
30 in stock, despatched in 4 working days

The Mean Well ELG-150-12A-3Y is a LED driver and transformer with a constant voltage and constant current output, adjustable between 10.8 - 13.2 V DC, and a power rating of 120 W. It includes surge protection, overvoltage safeguards, and a PFC circuit, making it suitable for use on flammable surfaces. This LED power supply unit is ideal for powering LED strips and various LED applications, offering reliable and safe performance.
Type LED transformer
Connection Open end cable
Dim (L x W x H) 219 x 63 x 35.5 mm
Factory colour Metal
Height 35.5mm
Input voltage (max.) 305V AC
IP Rating IP65
Length 219mm
Max. output current 10A
Max. power 120W
Max. temperature 90°C
Min. input voltage 100V AC
Min. temperature -40°C
Misc Attribute Synchronised
Number of Inputs 1
Number of Outputs 1
Output current (max.) - rounded 10A
Output current (min.) 5A
Output voltage (max.) 13.2V DC
Output voltage (min.) 10.8V DC
Power (min.) 84W
Power range 84 up to 120 W
Protection Class I
Width 63mm
