Mean Well ELG-100-C700B-3Y ELG series LED driver 100W 700mA 3-in-1 dimmer

Mean Well
Order Code:

05-0450

Brand: Mean Well MPN: ELG-100-C700B-3Y EAN-13: 4021087038515
Qty Was Unit Price (Ex VAT)
1+ £40.68 £35.22
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 22/12/2025

The Mean Well ELG-100-C700B-3Y LED driver is a constant current power supply that delivers 100.1 W at 700 mA with a voltage range of 71 to 143 V DC. It features a 3-in-1 dimmer, is dimmable, and suitable for flammable surfaces, making it ideal for use on furniture and outdoor applications. It includes a PFC circuit and surge protection, ensuring reliable performance in various environments.
Type LED driver
Output Voltage 71V DC
Max Output Power 100.1W
Output Current 700mA
Colour Metal
Connection Open end cable
Dimensions (L x W x H) 199 x 63 x 35.5 mm
Height 35.5mm
IP Rating IP67
Length 199mm
Max. output current 700mA
Max. temperature +90°C
Min. temperature -40°C
Misc Attribute 1 Constant current
Misc Attribute 2 Pulsed
Number of Inputs 1
Number of Outputs 1
Protection Class I
Test mark CE, CB, MM, SELV, UL, ENEC
Width 63mm
