Mean Well DDR-60G-24 rail DC/DC converter 24V 2.5A 60W 1 output

Mean Well
Order Code:

05-0309

Brand: Mean Well MPN: DDR-60G-24 EAN-13: 4021087050685
Qty Unit Price (Ex VAT)
1+ £33.65
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 15/12/2025

The Mean Well DDR-60G-24 is a rail-mounted DC/DC converter designed for industrial applications, delivering an output of 24 V DC at 2.5 A with a total power of 60 W. It features a durable DIN rail mount configuration suitable for control panels and automation systems. Typical applications include powering communication devices, industrial equipment, and remote sensors.
Type Rail mounted DC/DC converter (DIN)
Output Voltage 24V DC
Connection Clamp
Dim (L x W x H) 52.5 x 54.5 x 90 mm
Efficiency 91%
Height 90mm
Input Voltage 9-36V DC
Input voltage (max.) 36V DC
Length 52.5mm
Max. output current 2.5A
Min. input voltage 9V DC
MTBF 611000h
Nominal Input Voltage 24 V/DC
Number of Outputs 1
Operating temperature (max.) +85°C
Operating temperature (min.) -40°C
Output current (max.) - rounded 2.5A
Output type (power supply units) Adjustable
Output voltage (max.) 28V DC
Output voltage (min.) 21.4V DC
Output voltage (nominal) 24V DC
Power 60W
Width 54.5mm
