Mean Well CSP-3000-400 SMPSU 400V DC 7.5A 3000W 1 pc

Mean Well
Standard range
Order Code:

05-0212

Brand: Mean Well MPN: CSP-3000-400
Qty Unit Price (Ex VAT)
1+ £583.84
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
27 in stock, despatched in 4 working days

The Mean Well CSP-3000-400 is a switch-mode power supply unit (SMPSU) with a rating of 400 V DC at 7.5 A, delivering a total power output of 3000 W. This PCB-mounted PSU features screw terminals and is equipped with solder lugs for secure connections. It is typically used in industrial applications requiring high-power DC voltage, such as automated machinery and large-scale power systems.
Type SMPSU
Connection Screw terminal
Dim (L x W x H) 278 x 177.8 x 63.5 mm
Height 63.5mm
Length 278mm
Max. output current 7.5A
Misc Attribute 1 CSP-3000-400
Misc Attribute 2 Pulsed
Misc Attribute 3 closed
MTBF 223800h
No. of outputs 1
Operating temperature (max.) +60°C
Operating temperature (min.) -20°C
Output current (max.) - rounded 7.5A
Output voltage (max.) 400V DC
Output voltage (min.) 400V DC
PFC Yes
Power 3000W
Weight 4000g
Width 177.8mm
