Mean Well APC-25-500 LED driver 25.2 W 0.5 A 15-50 V DC non-dimmable

Image Representative of Range

Mean Well APC-25-500 LED driver 25.2 W 0.5 A 15-50 V DC non-dimmable

Mean Well
Order Code:

05-0178

Brand: Mean Well MPN: APC-25-500 EAN-13: 4021087026734
Qty Unit Price (Ex VAT)
1+ £18.51
5+ £17.61
10+ £16.97
25+ £16.47
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack-order availability date - 13/12/2025

The Mean Well APC-25-500 is a reliable LED driver designed to deliver constant current. It features a power rating of 25.2 W with an output current of 0.5 A and a voltage range of 15 - 50 V DC. Ideal for powering LED strip lights, it includes integrated surge protection for enhanced safety.
Type LED driver
Output Voltage 11-36 V
Connection Open end cable
Dim (L x W x H) 84 x 57 x 29.5 mm
Height 29.5mm
Input voltage (max.) 264V AC
IP Rating IP30
Length 84mm
Max. output current 0.5A
Max. power 25.2W
Min. input voltage 90V AC
Misc Attribute 1 Constant current
Misc Attribute 2 switched-mode
Misc Attribute 3 Synchronised
Number of Inputs 1
Number of Outputs 1
Output current (details) 700mA
Output current (max.) - rounded 500mA
Output voltage (max.) 50V DC
Output voltage (min.) 15V DC
Power range 25.2 W (max)
Protection Class II
Width 57mm
