Marquardt 01050.5502-00 Microswitch 250V AC 5A Momentary On/(On)

The Marquardt 01050.5502-00 microswitch is a momentary miniature switch with a rating of 250 V AC and 5 A. It features a single On/(On) contact configuration, suitable for applications requiring temporary actuation such as in consumer electronics or control panels. Made by Marquardt, this microswitch is ideal for precise control needs in various industrial and domestic applications.

Type	Microswitch
Contact Configuration	SPDT
Switch Function	momentary
Current Rating (Amps)	5A
Voltage Rating - AC	250 VAC
Actuating Force	0.6N
Connection	Solder tag
Contact Type	1 change-over
Dim	(L x W x H) 6.4 x 19.8 x 10 mm
Height	10mm
Length	6.4mm
Maximum Temperature	+100°C
Min. temperature	-40°C
Switch position	1 x On/(On)
Switching Voltage	250V AC
Width	19.8mm
