Leuze Electronic 50127033 LE46C Light Barrier IP67/IP69K Plastic Housing

Leuze Electronic manufactures the one-way light barrier LE46C/4P-M12 50127033, which offers both light-ON and dark-ON sensing. The product is typically used for detecting objects or measuring distances in industrial automation settings. It is recognised for its reliable performance in environments requiring precise light barrier functionality.

Type	One-way light barrier
IP Rating	IP67/IP69K
Connector	M12 (4-pin)
Depth	44mm
Dim	(W x H x D) 20.5 x 77.4 x 44 mm
Height	77.4mm
Max. operating voltage	30V DC
Max. Range	150m
Maximum Temperature	+60°C
Min. operating voltage	10V DC
Min. temperature	-40°C
Misc Attribute	LE46C/4P-M12
Model	Receiver
Operating Voltage	10 - 30 V DC
Output Type	2x PNP Antivalent
Switching Frequency	500Hz
Transmitter type	LED red
Wavelength	630nm
Width	20.5mm
