LAPP 0104105 Heat 260 1 x 0.85 mm² White 100 m

ÖLFLEX® HEAT 260 SC single wires are used for wiring and connection in switchboards with higher heat formation, in measuring devices, oven, brick factories, heating devices, kitchen facilities and installations of chemical technology. An additional application area is, independent of high temperatures, the use in connection with highly aggressive medium. Excellent resistivity against acids, alkalies, solvents, synthetic liquidity, lacquers, petrol and oil.

Colour	White
AWG	Not Specified
Conductor Cross Section	0.85mm²
Conductor Stranding	1 x 0.85
Insulation Material	Polytetrafluoroethylene (PTFE)
Length	100m
Type	Heat-resistant cable
Conductor Material	Silver Plated Copper
Insulation Wall Thickness	0.85mm
Maximum Operating Temperature	260°C
Maximum Wire Size AWG	18
Minimum Operating Temperature	-190°C
Voltage Rating	300V
