JST ZHR-2 Socket Housing 2 Pins 1.50 mm Pitch Audible Click 1 Pc

Image Representative of Range

JST ZHR-2 Socket Housing 2 Pins 1.50 mm Pitch Audible Click 1 Pc

JST
Order Code:

04-4973

Brand: JST MPN: ZHR-2 EAN-13: 2050000917998
Qty Unit Price (Ex VAT)
100+ £0.050
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
3,617 available to back orderBack-order availability date - 09/01/2026

The JST socket housing ZHR-2 is a compact connector with 2 pins and a 1.50 mm contact spacing, measuring 4.5x3.4x4.2 mm. It is manufactured by JST and typically used in PCB connectors for electronics applications. Its small size and reliable connection make it suitable for compact electronic devices.
Type Socket housing cable
Number of Ways 2
Number of Rows 1
Colour Ecru
Case Material Polyamide
Connection Crimp
Connector contact surface Tin plated
Connector system wire-to-board
Connector Type Socket, straight
Contact Material Copper alloy
Cross Section 0.032 - 0.13mm²
CS 1.50mm
Dimensions (L x W x H) 4.5 x 3.4 x 4.3 mm
Height 4.3mm
Industrial packaging No
Insulation Material Polyamide
Length 4.5mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 1A
Nominal current - rounded value 1A
Nominal current (details) 1A
Nominal voltage (details) 50V AC
Pins per row 2
Series ZHR
Width 3.4mm
