JST S2B-PH-K-S (LF)(SN) PH Pin Strip 2 Pins 2mm Spacing Detachable Pre-tinned

Image Representative of Range

JST S2B-PH-K-S (LF)(SN) PH Pin Strip 2 Pins 2mm Spacing Detachable Pre-tinned

JST
Standard range
Order Code:

04-4925

Brand: JST MPN: S2B-PH-K-S (LF)(SN)
Qty Unit Price (Ex VAT)
1+ £0.140
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
622 in stock, despatched in 4 working days

The JST built-in pin strip, model S2B-PH-K-S (LF)(SN), is a compact, angled header with a 2 mm contact spacing and two pins. Measuring 5.9x4.5x9.4mm, this connector strip is commonly used in PCB applications. It is ideal for space-constrained electronic components requiring reliable and efficient connections.
No. of rows 1
Board contact surface Tin plated
Case material Polyamide
Connector contact surface Tin plated
Connector orientation Parallel (to the PCB)
Connector system wire-to-board
Connector type Pin strip, right angle
Contact material Phosphor bronze
Cross section 0.05 - 22mm²
CS 2mm
Dim (L x W x H) 5.9 x 4.5 x 9.4 mm
Factory colour Ecru
Height 9.4mm
Industrial packaging No
Insulation material Polyamide
Length 5.9mm
Manufacturer part # S2B-PH-K-S (LF)(SN)
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Misc Attribute 2 S2B-PH-K-S (LF)(SN)
Nominal current 2A
Nominal current - rounded value 2A
Nominal current (details) 2A
Nominal voltage (details) voltage:100V AC
Pin Ø 0.5mm
Pin shape Square
Pins 2
Pins per row 2
RoHS-compliant Yes
Series PH
Total number of pins 2
Type Built-in pin strip (standard)
Width 4.5mm
