JST S14B-PHDSS (LF)(SN) PHD Strip 14-Pin 2-Row 2mm for Cable to PCB Connection

JST
Order Code:

04-4924

Brand: JST MPN: S14B-PHDSS (LF)(SN) EAN-13: 2050001028518
Qty Unit Price (Ex VAT)
10+ £0.720
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
287 in stock, despatched in 4 working days

The JST S14B-PHDSS (LF)(SN) is a precision built-in pin strip featuring a total of 14 pins with a contact spacing of 2 mm. Manufactured by JST, this component is ideal for connecting circuits in compact electronic devices. Typical applications include use in consumer electronics and industrial equipment for reliable signal transmission.
Type Built-in pin strip (precision)
Number of Rows 2
Board contact surface Tin plated
Case Material Polyamide
Connector contact surface Tin plated
Connector orientation Parallel (to the PCB)
Connector system wire-to-board
Connector Type Pin strip, right angle
Contact Material Copper alloy
Cross Section 0.08 - 0.33mm²
CS 2mm
Dim (L x W x H) 15.9 x 5 x 8 mm
Factory colour Ecru
Height 8mm
Industrial packaging No
Insulation Material Polyamide
Length 15.9mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Angled connector strip
Nominal Current 3A
Nominal current - rounded value 3A
Nominal current (details) 3A
Nominal voltage (details) 250V AC
Pin Ø 0.5mm
Pin shape Square
Pins 2 x 7
Pins per row 7
Series PHD
Total number of pins 14
Width 5mm
