JST S12B-PH-K-S (LF)(SN) PH Pin Strip 12 Pins 2mm Spacing Pre-tin Coated

Image Representative of Range

JST S12B-PH-K-S (LF)(SN) PH Pin Strip 12 Pins 2mm Spacing Pre-tin Coated

JST
Order Code:

04-4923

Brand: JST MPN: S12B-PH-K-S (LF)(SN) EAN-13: 2050000918643
Qty Unit Price (Ex VAT)
10+ £0.450
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
140 in stock, despatched in 4 working days

JST manufactures the angled 12-pin header with contact spacing of 2 mm, under the part number S12B-PH-K-S (LF)(SN). Its dimensions are 25.9 mm x 4.5 mm x 9.4 mm, making it suitable for PCB connectors. This built-in pin strip is commonly used in electronic and industrial applications for solid and reliable connections.
Type Built-in pin strip (standard)
Number of Rows 1
Board contact surface Tin plated
Case Material Polyamide
Connector contact surface Tin plated
Connector orientation Parallel (to the PCB)
Connector system wire-to-board
Connector Type Pin strip, right angle
Contact Material Phosphor bronze
Cross Section 0.05 - 22mm²
CS 2mm
Dim (L x W x H) 25.9 x 4.5 x 9.4 mm
Factory colour Ecru
Height 9.4mm
Industrial packaging No
Insulation Material Polyamide
Length 25.9mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 2A
Nominal current - rounded value 2A
Nominal current (details) 2A
Nominal voltage (details) voltage:100V AC
Pin Ø 0.5mm
Pin shape Square
Pins 12
Pins per row 12
Series PH
Total number of pins 12
Width 4.5mm
