JST PHR-12 Socket Housing 12 Pins 2mm Spacing Click-Lock Pre-Tin Coated

Image Representative of Range

JST PHR-12 Socket Housing 12 Pins 2mm Spacing Click-Lock Pre-Tin Coated

JST
Order Code:

04-4904

Brand: JST MPN: PHR-12 EAN-13: 2050000918421
Qty Unit Price (Ex VAT)
50+ £0.140
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
250 in stock, despatched in 4 working days

The JST socket housing cable PHR-12 is a connector with 12 pins and a contact spacing of 2 mm, ideal for various electronic applications. Manufactured by JST, it has dimensions of 25.8x4.5x6.4 mm, making it suitable for compact PCB connections. This component is typically used in electronic and electrical devices for secure and reliable connections.
Type Socket housing cable
Case Material Polyamide
Connection Crimp
Connector contact surface Tin plated
Connector system wire-to-board
Connector Type Socket, straight
Contact Material Copper alloy
Cross Section 0.05 - 22mm²
CS 2mm
Dim (L x W x H) 25.8 x 25.8 x 9.4 mm
Factory colour Ecru
Height 9.4mm
Industrial packaging No
Insulation Material Polyamide
Length 25.8mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 2A
Nominal current - rounded value 2A
Nominal current (details) 2A
Nominal voltage (details) voltage:100V AC
Number of Rows 1
Pins 12
Pins per row 12
Series PHR
Total number of pins 12
Width 25.8mm
