JST PHR-10 Socket 10 Pins 2mm Contact Audible Click Pre-Tin Coated

Image Representative of Range

JST PHR-10 Socket 10 Pins 2mm Contact Audible Click Pre-Tin Coated

JST
Order Code:

04-4902

Brand: JST MPN: PHR-10 EAN-13: 2050000918414
Qty Unit Price (Ex VAT)
50+ £0.155
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
329 in stock, despatched in 4 working days

JST manufactures the PHR-10 socket housing cable, featuring 10 pins with a contact spacing of 2 mm. It measures 21.8 x 4.5 x 6.4 mm and is part of their range of PCB connectors. This component is typically used in electronic applications requiring reliable connections on printed circuit boards.
Case Material Polyamide
Connection Crimp
Connector contact surface Tin plated
Connector system wire-to-board
Connector Type Socket, straight
Contact Material Copper alloy
Cross Section 0.05 - 22mm²
CS 2mm
Dim (L x W x H) 21.8 x 21.8 x 9.4 mm
Factory colour Ecru
Height 9.4mm
Industrial packaging No
Insulation Material Polyamide
Length 21.8mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 2A
Nominal current - rounded value 2A
Nominal current (details) 2A
Nominal voltage (details) voltage:100V AC
Number of Rows 1
Pins 10
Pins per row 10
Series PHR
Total number of pins 10
Type Socket housing cable
Width 21.8mm
