JST B9B-PH-K-S (LF)(SN) PH Pin Strip 9 Pins 2mm Contact Solderable Pre-Tin

Image Representative of Range

JST B9B-PH-K-S (LF)(SN) PH Pin Strip 9 Pins 2mm Contact Solderable Pre-Tin

JST
Order Code:

04-4891

Brand: JST MPN: B9B-PH-K-S (LF)(SN) EAN-13: 2050000918520
Qty Unit Price (Ex VAT)
10+ £0.403
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
69 in stock, despatched in 4 working days

JST manufactures a connector pin strip with nine pins and a contact spacing of 2 mm, identified as B9B-PH-K-S (LF)(SN). Its dimensions are 19.9 x 4.5 x 9.4 mm, making it suitable for practical use in various printed circuit board applications. Typically, it serves to connect electronic components within PCB assemblies, ensuring efficient electrical pathways in compact spaces.
Type Built-in pin strip (standard)
Number of Rows 1
Board contact surface Tin plated
Case Material Polyamide
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system wire-to-board
Connector Type Pin strip, straight
Contact Material Phosphor bronze
Cross Section 0.05 - 22mm²
CS 2mm
Dim (L x W x H) 19.9 x 4.5 x 9.4 mm
Factory colour Ecru
Height 9.4mm
Industrial packaging No
Insulation Material Polyamide
Length 19.9mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 2A
Nominal current - rounded value 2A
Nominal current (details) 2A
Nominal voltage (details) voltage:100V AC
Pin Ø 0.5mm
Pin shape Square
Pins 9
Pins per row 9
Series PH
Total number of pins 9
Width 4.5mm
