JST B6PS-VH (LF)(SN) Pin Strip 6-Pin 3.96mm Vibration Proof Safety Rail

JST B6PS-VH (LF)(SN) Pin Strip 6-Pin 3.96mm Vibration Proof Safety Rail

JST
Order Code:

04-4883

Brand: JST MPN: B6PS-VH (LF)(SN) EAN-13: 2050000917950

Discontinued


The JST connector strip, model B6PS-VH (LF)(SN), features six pins with a contact spacing of 3.96 mm, and measures 23.7 x 14.9 x 8.5 mm. This component is typically used in printed circuit boards for connecting multiple electrical circuits securely. Its angled design makes it suitable for use in compact or enclosed electronic devices.
Type Pin strip (standard)
Number of Positions 6
Number of Rows 1
Board contact surface Tin plated
Case Material Polyamide
Colour Ecru
Connector contact surface Tin plated
Connector orientation Parallel (to the PCB)
Connector system wire-to-board
Connector Type Pin strip, right angle
Contact Material Phosphor bronze
Cross Section 3.96mm
Dimensions (L x W x H) 23.7 x 14.6 x 8.5 mm
Height 8.5mm
Industrial packaging No
Insulation Material Polyamide
Length 23.7mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 10A
Nominal Voltage 250V AC
Pin Ø 1.14mm
Pin shape Square
Pins per row 6
Series VH
Width 14.6mm
