JST B6P-VH (LF)(SN) VH Pin Strip 6 Pins 3.96mm Spacing Solderable

Image Representative of Range

JST B6P-VH (LF)(SN) VH Pin Strip 6 Pins 3.96mm Spacing Solderable

JST
Order Code:

04-4884

Brand: JST MPN: B6P-VH (LF)(SN) EAN-13: 2050000917912
Qty Unit Price (Ex VAT)
20+ £0.350
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
118 in stock, despatched in 4 working days

The JST connector pin strip is a straight, 6-pole component with a contact spacing of 3.96 mm, measuring 23.7 x 14.6 x 8.5 mm. It is typically used in printed circuit boards (PCBs) for electrical connections. Manufactured by J.S.T., this pin strip is ideal for general connector applications in electronic assemblies.
Type Pin strip (standard)
Number of Rows 1
Board contact surface Tin plated
Case Material Polyamide
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system wire-to-board
Connector Type Pin strip, straight
Contact Material Phosphor bronze
Cross Section 0.33 - 1.25mm²
CS 3.96mm
Dim (L x W x H) 23.7 x 14.6 x 8.5 mm
Factory colour Ecru
Height 8.5mm
Industrial packaging No
Insulation Material Polyamide
Length 23.7mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 10A
Nominal current - rounded value 10A
Nominal current (details) 10A
Nominal Voltage 250V AC
Nominal voltage (details) 250V AC
Pin Ø 1.14mm
Pin shape Square
Pins 6
Pins per row 6
Series VH
Total number of pins 6
Width 14.6mm
