JST B5PS-VH (LF)(SN) VH Pin Strip 5-Pin 3.96mm Vibration-Proof Locking

Image Representative of Range

JST B5PS-VH (LF)(SN) VH Pin Strip 5-Pin 3.96mm Vibration-Proof Locking

JST
Order Code:

04-4878

Brand: JST MPN: B5PS-VH (LF)(SN) EAN-13: 2050000917943
Qty Unit Price (Ex VAT)
10+ £0.465
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
213 in stock, despatched in 4 working days

The JST B5PS-VH (LF) (SN) is a connector strip with five pins and a 3.96 mm contact spacing. Manufactured by JST, it features a compact size of 19.74x14.9x8.5 mm and is designed for angled connections on printed circuit boards. It is typically used in electronic and electrical applications requiring secure and reliable PCB connections.
Type Pin strip (standard)
Number of Positions 5
Number of Rows 1
Board contact surface Tin plated
Case Material Polyamide
Colour Ecru
Connector contact surface Tin plated
Connector orientation Parallel (to the PCB)
Connector system wire-to-board
Connector Type Pin strip, right angle
Contact Material Phosphor bronze
Cross Section 3.96mm
Dimensions (L x W x H) 19.74 x 14.6 x 8.5 mm
Height 8.5mm
Industrial packaging No
Insulation Material Polyamide
Length 19.74mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 10A
Nominal Voltage 250V AC
Pin Ø 1.14mm
Pin shape Square
Pins per row 5
Series VH
Width 14.6mm
