JST B4P-VH (LF)(SN) VH Pin Strip 4 Pins 3.96mm Vibration-proof Locking

Image Representative of Range

JST B4P-VH (LF)(SN) VH Pin Strip 4 Pins 3.96mm Vibration-proof Locking

JST
Order Code:

04-4873

Brand: JST MPN: B4P-VH (LF)(SN) EAN-13: 2050000917899
Qty Unit Price (Ex VAT)
20+ £0.170
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
283 in stock, despatched in 4 working days

JST manufactures a pin strip connector, B4P-VH (LF)(SN), featuring four pins with 3.96 mm contact spacing. This component is typically used in printed circuit boards for ensuring reliable electrical connections. Its compact dimensions (15.78x14.6x8.5 mm) make it suitable for tight spaces in electronic assemblies.
Type Pin strip (standard)
Number of Rows 1
Board contact surface Tin plated
Case Material Polyamide
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system wire-to-board
Connector Type Pin strip, straight
Contact Material Phosphor bronze
Cross Section 0.33 - 1.25mm²
CS 3.96mm
Dim (L x W x H) 15.78 x 14.6 x 8.5 mm
Factory colour Ecru
Height 8.5mm
Industrial packaging No
Insulation Material Polyamide
Length 15.78mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 10A
Nominal current - rounded value 10A
Nominal current (details) 10A
Nominal Voltage 250V AC
Nominal voltage (details) 250V AC
Pin Ø 1.14mm
Pin shape Square
Pins 4
Pins per row 4
Series VH
Total number of pins 4
Width 14.6mm
