JST B4B-PH-K-S (LF)(SN) 4-Pin Strip 2mm Spacing Pre-tin Reverse Protection

Image Representative of Range

JST B4B-PH-K-S (LF)(SN) 4-Pin Strip 2mm Spacing Pre-tin Reverse Protection

JST
Order Code:

04-4868

Brand: JST MPN: B4B-PH-K-S (LF)(SN) EAN-13: 2050000918476
Qty Unit Price (Ex VAT)
50+ £0.144
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
353 in stock, despatched in 4 working days

JST manufactures the B4B-PH-K-S (LF)(SN), a four-pin connector pin strip with 2 mm contact spacing. This compact connector measures 9.9x4.5x9.4 mm, making it suitable for space-restricted applications. It is typically used in electronic and PCB connections for secure and reliable interconnections.
Type Built-in pin strip (standard)
Number of Rows 1
Board contact surface Tin plated
Case Material Polyamide
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system wire-to-board
Connector Type Pin strip, straight
Contact Material Phosphor bronze
Cross Section 0.05 - 22mm²
CS 2mm
Dim (L x W x H) 9.9 x 4.5 x 9.4 mm
Factory colour Ecru
Height 9.4mm
Industrial packaging No
Insulation Material Polyamide
Length 9.9mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 2A
Nominal current - rounded value 2A
Nominal current (details) 2A
Nominal voltage (details) voltage:100V AC
Pin Ø 0.5mm
Pin shape Square
Pins 4
Pins per row 4
Series PH
Total number of pins 4
Width 4.5mm
