JST B3B-PH-K-S (LF)(SN) Pin Strip 3-Pin 2mm Spacing Pre-Tin Coated

Image Representative of Range

JST B3B-PH-K-S (LF)(SN) Pin Strip 3-Pin 2mm Spacing Pre-Tin Coated

JST
Order Code:

04-4862

Brand: JST MPN: B3B-PH-K-S (LF)(SN) EAN-13: 2050000918469
Qty Unit Price (Ex VAT)
50+ £0.115
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
335 in stock, despatched in 4 working days

JST's B3B-PH-K-S (LF)(SN) is a built-in pin strip connector featuring three pins with 2 mm contact spacing, ideal for compact electronic projects. Dimensions are 7.9x4.5x9.4mm, suitable for mounting on printed circuit boards. Commonly used in electronics for secure connections in industrial, consumer, and automotive applications.
Type Built-in pin strip (standard)
Number of Rows 1
Board contact surface Tin plated
Case Material Polyamide
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system wire-to-board
Connector Type Pin strip, straight
Contact Material Phosphor bronze
Cross Section 0.05 - 22mm²
CS 2mm
Dim (L x W x H) 7.9 x 4.5 x 9.4 mm
Factory colour Ecru
Height 9.4mm
Industrial packaging No
Insulation Material Polyamide
Length 7.9mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 2A
Nominal current - rounded value 2A
Nominal current (details) 2A
Nominal voltage (details) voltage:100V AC
Pin Ø 0.5mm
Pin shape Square
Pins 3
Pins per row 3
Series PH
Total number of pins 3
Width 4.5mm
