JST B2B-PH-K-S (LF)(SN) PH Built-in Pin Strip 2 Pins 2mm Spacing Audible Click

Image Representative of Range

JST B2B-PH-K-S (LF)(SN) PH Built-in Pin Strip 2 Pins 2mm Spacing Audible Click

JST
Order Code:

04-4857

Brand: JST MPN: B2B-PH-K-S (LF)(SN) EAN-13: 2050000918452
Qty Unit Price (Ex VAT)
50+ £0.120
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
510 in stock, despatched in 4 working days

The JST B2B-PH-K-S (LF)(SN) is a connector pin strip manufactured by JST with a total of two pins and a contact spacing of 2 mm. Its compact dimensions (5.9x4.5x9.4mm) and straight, built-in pin design make it suitable for PCB connections in electronics. This component is typically used in consumer electronics and automotive applications.
Type Built-in pin strip (standard)
Number of Rows 1
Board contact surface Tin plated
Case Material Polyamide
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system wire-to-board
Connector Type Pin strip, straight
Contact Material Phosphor bronze
Cross Section 0.05 - 22mm²
CS 2mm
Dim (L x W x H) 5.9 x 4.5 x 9.4 mm
Factory colour Ecru
Height 9.4mm
Industrial packaging No
Insulation Material Polyamide
Length 5.9mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 2A
Nominal current - rounded value 2A
Nominal current (details) 2A
Nominal voltage (details) voltage:100V AC
Pin Ø 0.5mm
Pin shape Square
Pins 2
Pins per row 2
Series PH
Total number of pins 2
Width 4.5mm
