JST B12B-PH-K-S (LF)(SN) PH Pin Strip 12 Pins 2mm Contact Spacing Pre-Tin Coated

Image Representative of Range

JST B12B-PH-K-S (LF)(SN) PH Pin Strip 12 Pins 2mm Contact Spacing Pre-Tin Coated

JST
Standard range
Order Code:

04-4850

Brand: JST MPN: B12B-PH-K-S (LF)(SN)
Qty Was Unit Price (Ex VAT)
1+ £0.527   £0.365
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
39 in stock, despatched in 4 working days

The JST built-in pin strip, model B12B-PH-K-S (LF)(SN), features 12 pins with a contact spacing of 2 mm. This connector pin strip is commonly used in electronic devices for reliable PCB connections. With dimensions of 25.9 x 4.5 x 9.4 mm, it is suitable for compact and precise applications.
No. of rows 1
Case material Polyamide
Connector orientation Perpendicular (to the PCB)
Connector system wire-to-board
Connector type Pin strip, straight
Contact material Phosphor bronze
Contact surface Tin plated
Cross section 0.05 - 22mm²
CS 2mm
Dim (L x W x H) 25.9 x 4.5 x 9.4 mm
Factory colour Ecru
Height 9.4mm
Industrial packaging No
Insulation material Polyamide
Length 25.9mm
Manufacturer part # B12B-PH-K-S (LF)(SN)
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Misc Attribute 2 B12B-PH-K-S (LF)(SN)
Nominal current 2A
Nominal current - rounded value 2A
Nominal current (details) 2A
Nominal voltage (details) voltage:100V AC
Pin Ø 0.5mm
Pin shape Square
Pins 12
Pins per row 12
RoHS-compliant Yes
Series PH
Total number of pins 12
Type Built-in pin strip (standard)
Width 4.5mm
