JST B10B-PH-K-S (LF)(SN) PH Pin Strip 10 Pins 2mm Spacing Audible Click

Image Representative of Range

JST B10B-PH-K-S (LF)(SN) PH Pin Strip 10 Pins 2mm Spacing Audible Click

JST
Order Code:

04-4846

Brand: JST MPN: B10B-PH-K-S (LF)(SN) EAN-13: 2050000918537
Qty Unit Price (Ex VAT)
10+ £0.450
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
124 in stock, despatched in 4 working days

JST manufactures this built-in pin strip connector, featuring 10 pins with a contact spacing of 2 mm. It is commonly used in PCB connectors due to its straight design and compact dimensions of 21.9x4.5x9.4 mm. This connector is suitable for applications requiring reliable electrical connections in small electronic devices.
Type Built-in pin strip (standard)
Number of Rows 1
Board contact surface Tin plated
Case Material Polyamide
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system wire-to-board
Connector Type Pin strip, straight
Contact Material Phosphor bronze
Cross Section 0.05 - 22mm²
CS 2mm
Dim (L x W x H) 21.9 x 4.5 x 9.4 mm
Factory colour Ecru
Height 9.4mm
Industrial packaging No
Insulation Material Polyamide
Length 21.9mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Nominal Current 2A
Nominal current - rounded value 2A
Nominal current (details) 2A
Nominal voltage (details) voltage:100V AC
Pin Ø 0.5mm
Pin shape Square
Pins 10
Pins per row 10
Series PH
Total number of pins 10
Width 4.5mm
