JST 800260 XH Socket 8-Pin 2.50mm Reverse Voltage Protection

Image Representative of Range

JST 800260 XH Socket 8-Pin 2.50mm Reverse Voltage Protection

JST
Order Code:

04-4816

Brand: JST MPN: 800260 EAN-13: 2050000918711
Qty Unit Price (Ex VAT)
50+ £0.140
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
116 available to back orderBack-order availability date - 08/01/2026

The JST socket housing cable XH, manufactured by JST, features 8 pins with a contact spacing of 2.50 mm. Measuring 22.3x5.7x7.75 mm, it is ideal for use in printed circuit board (PCB) connectors. This component is commonly employed in various electronic devices for secure cable connections.
No. of Rows 1
No. of Ways 8
Contact Finish Copper alloy
Case Material Polyamide
Connection Crimp
Connector contact surface Tin plated
Connector system wire-to-board
Connector Type Socket, straight
Cross Section 0.08 -0.33mm²
CS 2.50mm
Dim (L x W x H) 22.3 x 5.75 x 10.4 mm
Factory colour Ecru
Height 10.4mm
Industrial packaging No
Insulation Material Polyamide
Length 22.3mm
Material (details) PA 66 UL94V-0
Misc Attribute 1 Connector pin strip, straight
Misc Attribute 2 XHP-8
Nominal Current 3A
Nominal current - rounded value 3A
Nominal current (details) 3A
Nominal voltage (details) 250V AC
Pins 8
Pins per row 8
Series XH
Type Socket housing cable
Width 5.75mm
