JST 800139 XH Socket Housing 3-Pin 2.50 mm Pre-Tin Click Fit

The JST socket housing cable XH has three pins and a contact spacing of 2.50 mm. Manufactured by J.S.T., this compact connector is ideal for PCB applications, with dimensions of 9.8x5.7x7.75 mm. It's commonly used in electronic components and connectors for efficient cable management.

Pitch	2.5mm
No. of Rows	1
No. of Ways	3
Case Material	Polyamide
Connection	Crimp
Connector contact surface	Tin plated
Connector System	wire-to-board
Connector Type	Socket, straight
Contact Finish	Copper alloy
Cross Section	0.08 -0.33mm²
CS	2.50mm
Dim	(L x W x H) 9.8 x 5.75 x 10.4 mm
Factory colour	Ecru
Height	10.4mm
Industrial packaging	No
Insulation Material	Polyamide
Length	9.8mm
Material (details)	PA 66 UL94V-0
Misc Attribute 1	Connector pin strip, straight
Misc Attribute 2	XHP-3
Nominal Current	3A
Nominal current - rounded value	3A
Nominal current (details)	3A
Nominal voltage (details)	250V AC
Pins	3
Pins per row	3
Series	XH
Type	Socket housing cable
Width	5.75mm
