JST 08R-JED PCB Socket 8 Pins 1.25mm Spacing 1A Vibration-proof

The JST socket housing PCB, model 08R-JED, is a compact connector with 8 pins and a contact spacing of 1.25 mm. Manufactured by JST, it is designed for high-density electronic applications where space is limited. Typical uses include connecting components in consumer electronics and small electronic devices.

Pitch	1.25mm
No. of Rows	2
No. of Ways	8
Board contact surface	Tin plated
Case Material	Polyamide
Connection	Print
Connector contact surface	Tin plated
Connector orientation	Perpendicular (to the PCB)
Connector System	board-to-board
Connector Type	Power strip, straight
Contact Finish	Phosphor bronze
CS	1.25mm
Factory colour	Ecru
Industrial packaging	No
Insulation Material	Polyamide
Nominal Current	3A
Nominal current - rounded value	3A
Pin shape	Rectangular
Pins per row	4
Series	JED
Type	Socket housing PCB
