JST 08JQ-BT JQ Socket Housing 8 Pin 2.50mm Vibration-Proof 3A

Image Representative of Range

JST 08JQ-BT JQ Socket Housing 8 Pin 2.50mm Vibration-Proof 3A

JST
Extended range
Order Code:

12-1667

Brand: JST MPN: 08JQ-BT EAN-13: 2050001722614
Qty Unit Price (Ex VAT)
1+ £1.05
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
Available to back orderBack order, lead time 4 weeks

The JST Socket housing PCB JQ by JST has 8 pins with a contact spacing of 2.50 mm. It is commonly used in electronic applications requiring a reliable connection between components on a printed circuit board. This socket housing is ideal for use in compact electronic devices and circuit assemblies.
No. of rows 1
Board contact surface Tin plated
Case material Polyamide
Connection Print
Connector contact surface Tin plated
Connector orientation Perpendicular (to the PCB)
Connector system board-to-board
Connector type Pin strip, straight
Contact material Phosphor bronze
CS 2.50mm
Dim (W x H) 6 mm x 9.5 mm
Factory colour Ecru
Height 9.5mm
Industrial packaging No
Insulation material Polyamide
Manufacturer part # 08JQ-BT
Misc Attribute 08JQ-BT
Nominal current 3A
Nominal current - rounded value 3A
Pin shape Rectangular
Pins per row 8
RoHS-compliant Yes
Series JQ
Total number of pins 8
Type Socket housing PCB
Width 6mm
