HoraeTec 080210-2-3 Main Tap Terminal 125A 690V PE 4 Clamps

HoraeTec
Standard range
Order Code:

09-4002

Brand: HoraeTec MPN: 080210-2-3 EAN-13: 4051589021234
Qty Unit Price (Ex VAT)
1+ £31.89
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
12 in stock, despatched in 4 working days

The HoraeTec 080210-2-3 main tap terminal features a brass body with a PA grey-white (RAL 7035) outer finish. It is designed to handle a current of 125 A at a voltage of 690 V and accommodates a PE conductor type, commonly used for protective earth connections. This product is typically applied in electrical installations requiring reliable earthing and is available in a package of five pieces.
Conductor type PE
Depth 55.7mm
Dim (W x H x D) 29.2 x 49.4 x 55.7 mm
Height 49.4mm
Misc Attribute 1 Main cable branch terminal 35 mm²-1-pin
Misc Attribute 2 Type C-moveable finger-safe, modular
Nominal current 125A
Nominal current - rounded value 125A
Nominal voltage 690V
Number of pins 1
Type Main tap terminal
Width 29.2mm
