Hongfa HFD2/024-S-D PCB Relay 24V DC 3A 2 Change-Overs 1 piece

Image Representative of Range

Hongfa HFD2/024-S-D PCB Relay 24V DC 3A 2 Change-Overs 1 piece

Hongfa
Order Code:

09-3994

Brand: Hongfa MPN: HFD2/024-S-D EAN-13: 2050001760807
Qty Unit Price (Ex VAT)
3+ £1.80
Price per unit {{ this._page.IncVat ? 'Inc' : 'Ex' }} VAT
Order in multiples of 1
172 available to back orderBack-order availability date - 09/01/2026

The Hongfa HFD2/024-S-D PCB relay is a compact printed circuit board relay that operates on 24 V DC and supports up to 3 A with two change-over contacts. It is suitable for various applications requiring reliable switching, such as in industrial control systems or automation equipment. This miniature relay offers versatility and efficiency for space-constrained electronic designs.
Type PCB relay
Coil Voltage 24V DC
Switching Current 3A
Length 20.2mm
Width 10.2mm
Height 10.6mm
Connection Solder pins
Contact Material Ag-AuAg8
Contact Type 2 change-overs
Control Mode monostable, 1 coil
Dim (L x W x H) 20.2 x 10.2 x 10.6 mm
Max. pick-up voltage 55.4V DC
Max. temperature +85°C
Min. pick-up voltage 19.2V DC
Min. temperature -40°C
Resistance (coil) 3840Ω
