GW Instek GPE-4323 Bench PSU 0-32V 0-3A 4 Outputs 212W

GW Instek
Standard range
Order Code:

09-2654

Brand: GW Instek MPN: 01GP432310GS EAN-13: 4719692509291
Qty Unit Price (Ex VAT)
1+ £358.94
Price per unit {{ IncVat ? 'Inc' : 'Ex' }} VAT
1 in stock, despatched in 4 working days

The gpe-X323 series offers output power of 192 to 217 watts, three independent isolated output channels (GPE-X323), high resolution, low noise, high reliability, key-lock function and compact dimensions. The gpe-X323 Series has another new paradigm for GW Instek in the manufacture of linear DC power supplies.

Type Bench PSU (adjustable voltage)
Calibrated to Manufacturer's standards (no certificate)
Dim (L x W x H) 306 x 210 x 155 mm
Height 155mm
Input voltage 230V AC
Length 306mm
Max. output current 3A
Max. temperature 40°C
Min. temperature 0°C
Misc Attribute 1 GPE-4323
Misc Attribute 2 Desktop
Misc Attribute 3 Linear
No. of outputs 4
Output current (min.) 0A
Output current 2 (max.) 3A
Output current 2 (min.) 0A
Output current 3 (max.) 1A
Output current 3 (min.) 0A
Output current 4 (max.) 1A
Output current 4 (min.) 0A
Output voltage (max.) 32V
Output voltage (min.) 0V
Output voltage 2 (max.) 32V
Output voltage 2 (min.) 0V
Output voltage 3 (max.) 5V
Output voltage 3 (min.) 0V
Output voltage 4 (max.) 15V
Output voltage 4 (min.) 0V
Power 212W
Residual ripple 1 mVrms
Technology Linear regulated PSU
Weight 7kg
Width 210mm
