Fujitsu FTR-K1Series PCB Relays 16A

Fujitsu Brand: Fujitsu

A range of low profile PCB mounting SPDT power relays that have high current rating and high insulation that make them ideal for a wide range of applications and for high density packing on PCBs.

  • 16A Current rating
  • 5mm Pitch
  • Low coil power
  • UL F class insulation wire
  • Cadmium free contacts
  • Flux proof RTII
  • UL, CSA, VDE, SEMKO approved
Description Image Product Buy Pricing (Ex VAT)
Fujitsu FTR-K1CK005W PCB Mount Mains Relay 5VDC 1CO SPDT
Fujitsu FTR-K1CK005W PCB Mount Mains Relay 5VDC 1CO SPDT
Standard range
Order code: 50-5632
MPN: FTR-K1CK005W

662 in stock, despatched in 4 working days
3+ £1.47
Price per unit Ex VAT
Fujitsu FTR-K1CK012W PCB Mount Mains Relay 12VDC 1CO SPDT
Fujitsu FTR-K1CK012W PCB Mount Mains Relay 12VDC 1CO SPDT
Standard range
Order code: 50-5633
MPN: FTR-K1CK012W

532 in stock, despatched in 4 working days
2+ £2.65
Price per unit Ex VAT
Fujitsu FTR-K1CK024W PCB Mount Mains Relay 24VDC 1CO SPDT
Fujitsu FTR-K1CK024W PCB Mount Mains Relay 24VDC 1CO SPDT
Standard range
Order code: 50-5634
MPN: FTR-K1CK024W

425 in stock, despatched in 4 working days
2+ £2.58
Price per unit Ex VAT
Order code50-563250-563350-5634
Contact data
Configuration1 Form C (SPDT)1 Form C (SPDT)1 Form C (SPDT)
MaterialAgSnO2AgSnO2AgSnO2
Rating16A 250V AC/24V DC16A 250V AC/24V DC16A 250V AC/24V DC
Contact resistance max.100mΩ100mΩ100mΩ
Max. carrying current16A16A16A
Min. switching load10mA 5V DC10mA 5V DC10mA 5V DC
Switching voltage max.440V AC/300V DC440V AC/300V DC440V AC/300V DC
Switching power max.4000VA/384W4000VA/384W4000VA/384W
Coil data
Rated coil voltage5V DC12V DC24V DC
Coil resistance62Ω360Ω1440Ω
Must operate voltage3.5V DC8.4V DC16.8V DC
Must release voltage0.5V DC1.2V DC2.4V DC
Coil voltage max.12.2V DC29.4V DC58.8V DC
Rated power400mW400mW400mW
Operate power200mW200mW200mW
Other
Insulation resistance>1000MΩ>1000MΩ>1000MΩ
Dielectric strength (contacts to coil)5kV AC5kV AC5kV AC
Surge strength10kV10kV10kV
Clearance10mm10mm10mm
Creepage10mm10mm10mm
Mechanical life>20 x 106 operations>20 x 106 operations>20 x 106 operations
Electrical life>50 x 103 operations>50 x 103 operations>50 x 103 operations
Operating temperature range–40°C to +70°C–40°C to +70°C–40°C to +70°C
Dimensions W x H x D (mm)29 x 15.7 x 12.729 x 15.7 x 12.729 x 15.7 x 12.7
