Fluke 5317738 1663 Electrical Tester Set reliable, comprehensive testing

Fluke 1663 DE multifunction tester, meets all local regulations, now bundled with Fluke TruTest™ data management and reporting software. Fluke TruTest software simplifies data management and reporting for instrument testing over traditional procedures. Whether you are testing equipment in an office, verifying repairs in a workshop, or conducting annual visual inspections, proper data management is critical to creating easy-to-understand reports for customers. The TruTest software enables quick and easy import of measurement results directly from test devices, management of files transferred from devices, and manual input of data as required.

Type	Electrical Tester
Maximum Capacitance	Not Applicable
Maximum Resistance	Not Applicable
Display Type	Digital (LCD)
Accuracy	0.8%
Calibrated to	Manufacturer's standards (no certificate)
Curve shape at RCD/FI testing	For earth leakage switch type A, F and type B, B+
Detection short-circuit current/overcurrent protection	true
Dim	(L x W x H) 100 x 250 x 125 mm
DIN Standard	DIN EN 61010-1
Earth loop measurement	false
Earthing measurement	true
Field rotation test	true
Height	125mm
Indication	Digital
Interface	true
IP Rating	IP40
Isolation resistance measurement	true
Isolation resistance measurement with ramp function	false
Length	100mm
Limit value indication	false
Loop measurement without RCD/FI release	true
Loop resistance/impedance measurement	true
Low resistance measurement	true
Low resistance measurement with ramp function	false
Mains internal resistance measurement	true
Measured value memory	true
Measuring of leakage currents with adaptor	false
Memory	Yes
Misc Attribute	FLUKE 1663 DE KIT
Overvoltage protector testing	false
PRCD testing type S, type K	false
Printer connection	false
Printer integrated	false
RCD/FI analysis function	true
RCD/FI testing	true
RCD/FI testing with rising residual current	true
Remote control for testing device	true
Resistances of isolating floors and walls	false
Selective earthing measurement	false
Specific earthing measurement	false
Structured measured value memory	true
Testing of charging devices E-Mobility, simulation of vehicle status	false
Testing of IMDs and RCMs	false
Voltage Supply	Battery
Width	250mm
