Unique feature for precise measurement of voltage and frequency of motor drive with variable speed, in which harmonics superimpose the 87 V base frequency. Thanks to an integrated thermometer, you can easily measure temperature without having to take a separate 87 V thermometer. Optional magnetic hanger for easy setup and reading, while your hands remain free for other tasks. Display with large digits and bright stage background lighting ensures that the series 80 V measuring instruments are much simpler to read than the older models.
| Type |
Multimeter |
| A AC reading range (min.) |
0.01mA |
| A DC reading range (max.) |
10A |
| AC resistance |
10MΩ |
| Amperage reading range AC (max.) |
10A |
| Amperage reading range DC (min.) |
0.01mA |
| Basic accuracy |
0.1% |
| Calibrated to |
Manufacturer's standards (no certificate) |
| Current reading |
AC/DC |
| Dc Resistance |
10MΩ |
| Dim |
(W x H) 98 mm x 201 mm |
| Display |
Digital |
| Display (counts) |
6000 |
| Frequency Range |
50 Hz - 5 kHzHz |
| Frequency reading range |
0.01 Hz - 200 kHz |
| Height |
201mm |
| Interfaces |
none |
| Measurement type (details) |
Average |
| Misc Attribute |
83V/EUR |
| Power supply (details) |
9 V battery |
| Reading range - capacity |
0.01 nF - 9999 µF |
| Reading range - resistance |
0.1 Ω - 50 MΩ |
| V AC reading range (max.) |
1000V |
| V AC reading range (min.) |
0.1mV |
| Voltage DC reading range (max.) |
1000V |
| Voltage metering |
AC/DC |
| Voltage reading range DC (min.) |
0.1mV |
| Width |
98mm |
