The Finder 7S.14.9.024.4220 relay by Finder features a nominal voltage of 24 V DC and a maximum switching current of 3 A. This industrial relay is ideal for automation tasks in industrial control panels and machinery. Typical applications include switching and controlling electrical loads in various industrial environments.
| Type |
Relay |
| Contact Material |
AgSnO2 |
| Depth |
96mm |
| Durability |
10 · 10^6 |
| Electrical lifespan |
100 · 10³ |
| Evaluation inputs |
2-channel |
| Fall Time |
10ms |
| Height |
78.8mm |
| IP Rating |
IP20 |
| Maximum Switching Load |
1500VA |
| Maximum Temperature |
70°C |
| Min. temperature |
-40°C |
| Model |
Expansion device |
| Nominal Voltage |
24V DC |
| Number of outputs, safety related, delayed, semiconductors |
N/A |
| Number of outputs, safety related, delayed, with contact |
N/A |
| Number of outputs, safety related, undelayed, semiconductors |
N/A |
| Number of outputs, safety related, undelayed, with contact |
2 |
| Number of outputs, signalling function, delayed, semiconductors |
N/A |
| Number of outputs, signalling function, delayed, with contact |
N/A |
| Number of outputs, signalling function, undelayed, semiconductors |
N/A |
| Number of outputs, signalling function, undelayed, with contact |
N/A |
| Performance level according to EN ISO 13849-1 |
Level d |
| Rated control supply voltage DC |
16.8 - 30 |
| Response Time |
12ms |
| SIL according to IEC 61508 |
2 |
| Stop category according to IEC 60204 |
N/A |
| Suitable for monitoring of emergency-stop circuits |
N/A |
| Suitable for monitoring of magnetic switches |
N/A |
| Suitable for monitoring of optoelectronic protection equipment |
N/A |
| Suitable for monitoring of position switches |
N/A |
| Suitable for monitoring of proximity switches |
N/A |
| Suitable for monitoring of tactile sensors |
N/A |
| Suitable for monitoring of valves |
N/A |
| Suitable for rail mounting |
true |
| Switching current (max.) |
3A |
| Type of electric connection |
Spring clamp connection |
| Type of safety according to IEC 61496-1 |
N/A |
| Voltage type for actuating |
DC |
| Width |
22.5mm |
| With approval according to UL |
true |
| With approval for BG BIA |
false |
| With approval for TÜV |
false |
| With detachable clamps |
false |
| With feedback circuit |
true |
| With muting function |
false |
| With start input |
false |
