Finder 7S.14.8.230.4310 Relay module 230V AC 3A SIL2 PL d IP20

The Finder 7S.14.8.230.4310 relay is a reliable industrial component by Finder, designed for a nominal voltage of 230 V AC and supports a maximum switching current of 3 A. It is ideal for use in a variety of industrial relay socket combos or modules. This relay is commonly used in automation and control systems for efficient electrical management.

Type	Relay
Contact Material	AgSnO2
Depth	96mm
Durability	10 · 10^6
Electrical lifespan	100 · 10³
Evaluation inputs	3-channel
Fall Time	10ms
Height	78.8mm
IP Rating	IP20
Max. temperature	70°C
Maximum Switching Load	1500VA
Min. temperature	-40°C
Model	Expansion device
Nominal Voltage	230V AC
Number of outputs, safety related, delayed, semiconductors	N/A
Number of outputs, safety related, delayed, with contact	N/A
Number of outputs, safety related, undelayed, semiconductors	N/A
Number of outputs, safety related, undelayed, with contact	3
Number of outputs, signalling function, delayed, semiconductors	N/A
Number of outputs, signalling function, delayed, with contact	N/A
Number of outputs, signalling function, undelayed, semiconductors	N/A
Number of outputs, signalling function, undelayed, with contact	N/A
Performance level according to EN ISO 13849-1	Level d
Rated control supply voltage AC 50 Hz	195 - 264
Rated control supply voltage AC 60 Hz	195 - 264
Response Time	12ms
SIL according to IEC 61508	2
Stop category according to IEC 60204	N/A
Suitable for monitoring of emergency-stop circuits	N/A
Suitable for monitoring of magnetic switches	N/A
Suitable for monitoring of optoelectronic protection equipment	N/A
Suitable for monitoring of position switches	N/A
Suitable for monitoring of proximity switches	N/A
Suitable for monitoring of tactile sensors	N/A
Suitable for monitoring of valves	N/A
Suitable for rail mounting	true
Switching current (max.)	3A
Type of electric connection	Spring clamp connection
Type of safety according to IEC 61496-1	N/A
Voltage type for actuating	AC
Width	22.5mm
With approval according to UL	true
With approval for BG BIA	false
With approval for TÜV	false
With detachable clamps	false
With feedback circuit	true
With muting function	false
With start input	false
