Finder 77D382308671 SSR 60 A 660 V AC Instantaneous 1 piece

Manufactured by Finder, the SSR 77D382308671 is a solid state relay with a maximum switching voltage of 660 V AC and a current rating of 60 A. Featuring zero crossing switching, it is ideal for applications requiring precise instantaneous switching. It is commonly used in industrial automation and lighting control systems.

Type	SSR
Contact Configuration	SPST-NO
Switching Current	60A
Switching Voltage	600V AC
Length	105mm
Width	78mm
Height	38mm
IP Rating	IP20
Max. temperature	+80°C
Min. temperature	-30°C
Misc Attribute	77.D3.8.230.8671
Number of Phases	3
Operating Voltage	24 - 660
Permanent current (max.)	60A
Rated control supply voltage AC 50 Hz	230 - 230V
Rated control supply voltage AC 60 Hz	230 - 230V
Rated operation current Ie at AC-1	60A
Rated operation current Ie at AC-3	N/A
Rated operation current Ie at AC-51	N/A
Rated operation current Ie at AC-53a	N/A
Rated operation current Ie at AC-53b	N/A
Suitable for distribution board	true
Switching at zero-crossing	false
Switching type	Instantaneous
Switching voltage (min.)	24V AC
Voltage type for actuating	AC
