Finder 77B190248250 SSR 40A 280V AC Zero crossing 1pc

The Finder SSR 77B190248250 is a solid state relay with a maximum switching voltage of 280 V AC and a current rating of 40 A. It features zero crossing technology, making it ideal for smooth and efficient power switching in various industrial and commercial applications. This electronic relay is commonly used in motor control, heater control, and lighting systems.

Type	SSR
Contact Configuration	SPST-NO
Switching Current	40A
Length	59mm
Width	45mm
Height	29.40mm
IP Rating	IP20
Max. temperature	+80°C
Min. temperature	-30°C
Misc Attribute	77.B1.9.024.8250
Number of Phases	1
Operating Voltage	24 - 280
Permanent current (max.)	40A
Rated control supply voltage DC	24 - 24V
Rated operation current Ie at AC-1	40A
Rated operation current Ie at AC-3	N/A
Rated operation current Ie at AC-51	N/A
Rated operation current Ie at AC-53a	N/A
Rated operation current Ie at AC-53b	N/A
Suitable for distribution board	true
Switching at zero-crossing	true
Switching type	Zero crossing
Switching voltage (min.)	24V AC
Voltage type for actuating	DC
