Finder 65.31.9.024.4309 Plug-in Relay 24 V DC 30 A 1 maker

The Finder 65.31.9.024.4309 is a plug-in relay designed for use with a 24 V DC power supply, capable of handling currents up to 30 A. This sturdy relay is ideal for printed circuit board applications, providing reliable switching in various electronic and industrial settings. Common applications include automation systems, control panels, and electrical equipment requiring dependable relay operation.

Coil Voltage	24V DC
Contact Configuration	1NO
Switching Current	30A
Coil Resistance	445O
Complete with socket	false
Connection	Faston connections 250 (6.35 x 0.8 mm).
Contact Material	AgSnO2
Degree of protection (IP)	N/A
Depth	36.5mm
Dimensions	(L x W x H) 36.50 x 32.20 x 42.20 mm
Drive, polarization	Polarity free
Drive, switching attitude	Mono stable
Durability	80 x 103 Switching operations
Height	42.20mm
IP Rating	Relay protection type RT I
Length	36.5mm
Material contact	Other copper alloys
Material of contact insert	Duroplast
Material of contact surface	Untreated
Max. pick-up Voltage	26.4V DC
Max. switching capacity	7500VA
Max. temperature	+75°C
Min. pick-up Voltage	20.4V DC
Minimum Temperature	-40°C
Misc Attribute 1	Faston-connections
Mounting Type	Plug-in
Nominal Current	30A
Number of contacts as change-over contact	0
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	1
Rated control supply voltage DC	24 - 24V
Switching Voltage	250V AC
Switching Voltage Max	400V AC
Temperature Range	-40 - +75°C
Type	Plug-in relay
Type of electric connection	Soldering flag connection
Type of switch contact	Double contact
Voltage type for actuating	DC
Width	32.20mm
With detachable clamps	N/A
With forced-guided contacts	false
With LED indication	false
