Finder 56.34.9.110.0000T Power Plug-in Relay 110V DC 12A 4 change-overs

The Finder 56.34.9.110.0000T is a plug-in relay designed for 110 V DC and capable of handling 12 A with 4 change-over contacts. This relay is suitable for use in applications requiring PCB mounting on printed circuit boards. It is commonly used in industrial automation, control panels, and electronic circuitry.

Coil Voltage	110V DC
Contact Configuration	4CO (4PDT)
Switching Current	12A
Complete with socket	false
Connection	Connector
Degree of protection (IP)	N/A
Depth	27.7mm
Dimensions	(W x H x D) 40.8 x 37.2 x 27.7 mm
Drive, polarization	Polarity free
Drive, switching attitude	Mono stable
Height	37.2mm
IP Rating	IP20
Length	27.7mm
Material contact	Other copper alloys
Material of contact insert	Duroplast
Material of contact surface	Untreated
Mounting Type	PCB
Nominal Current	12A
Number of contacts as change-over contact	4
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	0
Rated control supply voltage DC	110 - 110V
Type	Plug-in relay
Type of electric connection	Plug-in connection
Type of switch contact	Single contact
Voltage type for actuating	DC
Width	40.8mm
With detachable clamps	N/A
With forced-guided contacts	false
With LED indication	true
