Finder 56.32.9.024.0074 Relay 60V DC 12A 2 change-overs AgNi contact

Finder's plug-in relay, model 56.32.9.024.0074, handles 60 V DC with a current rating of 12 A. It features two change-over contacts, suitable for printed circuit board mounting. This mini relay is commonly used in industrial automation and control systems.

Coil Voltage	60V DC
Contact Configuration	2CO (DPDT)
Switching Current	12A
Complete with socket	false
Connection	Connector
Degree of protection (IP)	N/A
Depth	27.7mm
Dimensions	(W x H x D) 20.7 x 37.7 x 27.7 mm
Drive, polarization	Polarity free
Drive, switching attitude	Mono stable
Height	37.7mm
IP Rating	IP20
Length	27.7mm
Material contact	Other copper alloys
Material of contact insert	Duroplast
Material of contact surface	Untreated
Mounting Type	Plug-in
Nominal Current	12A
Number of contacts as change-over contact	2
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	0
Rated control supply voltage DC	24 - 24V
Type	Plug-in relay
Type of electric connection	Plug-in connection
Type of switch contact	Single contact
Voltage type for actuating	DC
Width	20.7mm
With detachable clamps	N/A
With forced-guided contacts	false
With LED indication	true
