Finder 56.32.9.024.0070 Plug-in Relay 60 V DC 12 A 2 change-overs

The Finder plug-in relay model 56.32.9.024.0070 features a 60 V DC coil and supports up to 12 A with 2 change-over contacts. It is suitable for use in applications requiring reliable electric switching on printed circuit boards. This mini relay is ideal for PCB mounting in automation systems and electronic devices.

Coil Voltage	60V DC
Contact Configuration	2CO (DPDT)
Switching Current	12A
Complete with socket	false
Connection	Connector
Degree of protection (IP)	N/A
Depth	27.7mm
Dimensions	(W x H x D) 20.7 x 37.7 x 27.7 mm
Drive, polarization	Polarity free
Drive, switching attitude	Mono stable
Height	37.7mm
IP Rating	IP20
Length	27.7mm
Material contact	Other copper alloys
Material of contact insert	Duroplast
Material of contact surface	Untreated
Mounting Type	PCB
Nominal Current	12A
Number of contacts as change-over contact	2
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	0
Rated control supply voltage DC	24 - 24V
Type	Plug-in relay
Type of electric connection	Plug-in connection
Type of switch contact	Single contact
Voltage type for actuating	DC
Width	20.7mm
With detachable clamps	N/A
With forced-guided contacts	false
With LED indication	true
