Finder 55.34.9.125.0090 Plug-in Relay 125V DC 7A 4 change-overs

The Finder 55.34.9.125.0090 is a plug-in relay designed to operate at 125 V DC with a current capacity of 7 A and features four change-overs. This compact and efficient relay is suitable for use in printed circuit boards and mini-relay applications. Typical applications include industrial automation, switching, and control systems.

Coil Voltage	125V DC
Contact Configuration	4CO (4PDT)
Switching Current	7A
Complete with socket	false
Connection	Connector
Degree of protection (IP)	N/A
Depth	27.7mm
Dimensions	(W x H x D) 20.7 x 37.2 x 27.7 mm
Drive, polarization	Polarized
Drive, switching attitude	Mono stable
Height	37.2mm
IP Rating	IP20
Length	27.7mm
Material contact	Other copper alloys
Material of contact insert	Duroplast
Material of contact surface	Untreated
Mounting Type	Plug-in
Nominal Current	7A
Number of contacts as change-over contact	4
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	0
Rated control supply voltage DC	125 - 125V
Type	Plug-in relay
Type of electric connection	Plug-in connection
Type of switch contact	Single contact
Voltage type for actuating	DC
Width	20.7mm
With detachable clamps	N/A
With forced-guided contacts	false
With LED indication	true
