Finder 55.32.9.060.5040 Plug-in Relay 60V DC 10A 2 change-overs

The Finder 55.32.9.060.5040 is a plug-in relay with a 60 V DC coil and a 10 A current rating. It features two change-over contacts and is suitable for PCB mounting. This relay is typically used in control panels and automation systems.

Coil Voltage	60V DC
Contact Configuration	2CO (DPDT)
Switching Current	10A
Complete with socket	false
Connection	Connector
Degree of protection (IP)	N/A
Depth	27.7mm
Dimensions	(W x H x D) 20.7 x 37.2 x 27.7 mm
Drive, polarization	Polarity free
Drive, switching attitude	Mono stable
Height	37.2mm
IP Rating	IP20
Length	27.7mm
Material contact	Other copper alloys
Material of contact insert	Duroplast
Material of contact surface	Gold
Mounting Type	PCB
Nominal Current	10A
Number of contacts as change-over contact	2
Number of contacts as normally closed contact	0
Number of contacts as normally open contact	0
Rated control supply voltage DC	60 - 60V
Type	Plug-in relay
Type of electric connection	Plug-in connection
Type of switch contact	Single contact
Voltage type for actuating	DC
Width	20.7mm
With detachable clamps	N/A
With forced-guided contacts	false
With LED indication	true
